Products Description
| Product Name | Product Description | Capabilities Applied/Processes |
Hydraulic turbine main shaft seal ring |
Turbine spindle seals can protect the turbine | It prevents flooding of the turbine guide bearings and top cover and is capable of maintaining normal operation of the bearings and the unit. |
|
Material Used |
PTFE |
|
Benefits |
Excellent friction and wear resistance |
|
Industry for Use |
Hydropower industry |
The Role of Hydraulic Turbine Main Shaft Seal Ring
The hydraulic turbine main shaft seal ring can play a protective role for the hydraulic turbine, the use of this device can ensure the normal operation of the hydraulic turbine, and it can effectively block the water flow from the gap between the main shaft and the top cover overflow, to prevent the hydraulic turbine guide bearings and the top cover is flooded, to maintain the normal operation of the bearings and units.
Advantages of Hydraulic Turbine Main Shaft Seal Ring
- The main shaft seal ring can effectively prevent the leakage of pressurized water from the rotating part to the fixed part, thus protecting the safe operation of the turbine.
- Hydraulic turbine main shaft seal ring is usually made of wear-resistant materials, which can provide high wear resistance and long life under harsh working conditions.
- The seal ring design allows automatic adjustment when the load changes to maintain good sealing performance.
Technical data
| PTFE | Property | Unit | Test Method | Test Parameter | Value |
| Specific gravity | g/cm3 | ASTM D792 | 2.15 | ||
| Hardness | Shore D | ASTM D2240 | (Shore D - 15 sec) | 59 | |
| Tensile strength | MPa | ASTM D638 | Microtensile specimen of ASTM D1708, speed of testing 0.8mm/s |
27.5 | |
| Ultimate elongation | % | ASTM D638 | Microtensile specimen of ASTM D1708, speed of testing 0.8mm/s |
300 | |
| Modulus of Elasticity | MPa | ASTM D638 | 280 | ||
| Dielectric Strength (short time test) | kV/mm | ASTM D149 | 35.5 |
certification
